Electronic Generator
Controller Module Control Panel For Dc20d Mkii Engine
USD $49.15
Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
Description:
Microcomputer control.
Manual/automatic start and stop.
5-digit LED digital tube displays the operating status and parameters of the unit.
LED indicator and fault code display alarm indication.
With two programmable output relays.
It can be used for a variety of models through custom settings.
Feature:
Control function:
Automatic control of cranking.
Start delay control.
Local manual start/stop.
Remote automatic start/stop.
Automatically back off the starter motor, the oil pressure switch backs off the motor.
Preheat control.
Cooler control.
Parking/idling control.
Parameter display:
Engine speed.
Generator frequency.
Generator AC voltage.
Engine battery voltage.
Engine oil pressure.
Engine water temperature.
Cumulative running time.
Protective function:
Lubricating oil pressure protection.
Low cooling water level protection.
High cooling water temperature protection.
Generator overvoltage protection.
Overclocking/Overspeeding Protection.
Emergency shutdown of generator set.
Failed to stop the engine.
Engine fails to start.
Low fuel level warning.
Low battery voltage warning.
High performance,reliable quality.
We work with every effort to provide quality products and professional service.
Specification:
Size: 78*75*76mm
AC Input: AC 20-80V
Equipment Type: Control Panel
Measuring Frequency: 10-70Hz
Comfigurable output: Max 3.5A
Excitation Output: Max 1A
Model: DC20D MKII
Features: Microcomputer control
DC Supply: DC 8-36V
Fuel output: Max3.5A
Power Consumption: Max 3W
Panel Cut-out: 67*67mm
About Delivery:
We have warehouses in California and New Jersey.
We will follow the principle of nearest delivery.
When one warehouse is out of stock, it will be shipped from another warehouse.
Thank you for your understanding.
Package Product List:
1 × DC20D MKII Generator Control Module
2 × Mounting screws
1 × Cable
1 × Instruction Manual
Item SpecificsBrand marddpairMPN 1903567Type Generator Controller ModuleCustom Bundle NoBundle Description NoModified Item NoModel DC20D MKIIFeatures Microcomputer controlSize 78*75*76mmAC Input AC 20-80VEquipment Type Control PanelMeasuring Frequency 10-70HzComfigurable output Max 3.5AExcitation Output Max 1ADC Supply DC 8-36VFuel output Max3.5APower Consumption Max 3WPanel Cut-out 67*67mmRelay output Start output:Max 3.5AWarranty 1 Year
